6-16 Bulletin 284 Programmable Parameters for Sensorless Vector Controllers
OutA DN FltState
This parameter in conjunction with Parameter 36 defines how Output A will respond
when a DeviceNet network fault occurs. When set to 1, Output A will hold state prior
to trip occurrence. When set to 0, Output A will open or close as determined by
setting in Parameter 36. Parameter Number 35
Access Rule GET/SET
Data Type BOOL
Group User I/O
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
OutA DN FltValue
This parameter determines the state that Output A assumes when a DeviceNet
network fault occurs and Parameter 35 is set to 0.
0 = Open
1 = Close Parameter Number 36
Access Rule GET/SET
Data Type BOOL
Group User I/O
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
OutA DN IdlState
This parameter in conjunction with Parameter 38 defines how Output A will respond
when the DeviceNet network is idle. When set to 0, Output A will open or close as
determined by the setting in Parameter 38.
The DN Flt parameters supersede the Dn Idl parameters. Parameter Number 37
Access Rule GET/SET
Data Type BOOL
Group User I/O
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
OutA DN IdlValue
This parameter determines the state that Output A assumes when the network is idle
and Parameter 37 is set to 0.
0 = Open
1 = Closed Parameter Number 38
Access Rule GET/SET
Data Type BOOL
Group User I/O
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
OutB Pr FltState
This parameter in conjunction with Parameter 40 defines how Output B will respond
when a trip. When set to 1, Output B continue to operate as command via the
network. When set to 0, Output B will open or close as determined by setting in
Parameter 40. Parameter Number 39
Access Rule GET/SET
Data Type BOOL
Group User I/O
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
