Bulletin 284 Programmable Parameters for Volts per Hertz Controllers 5-35
Basic Program Group
Motor NP Volts
Set to the motor nameplate rated volts. Parameter Number 131
Related Parameters 104, 184
Access Rule GET/SET
Data Type UINT
Group Basic Program Setup
Units 1V AC
Minimum Value 20
Maximum Value 240V, 460V, or 600V AC
Default Value Based on Drive Rating
Motor NP Hertz
Set to the motor nameplate rated frequency. Parameter Number 132
Related Parameters 184, 190
Access Rule GET/SET
Data Type UINT
Group Basic Program Setup
Units 1 Hz
Minimum Value 10
Maximum Value 240
Default Value 60 Hz
Motor OL Current
Set to the maximum allowable current. The drive will fault on an F7 Motor Over load
if the value of this parameter is exceeded by 150% for 60 seconds. Parameter Number 133
Related Parameters 155, 189, 190, 198, 214
Access Rule GET/SET
Data Type UINT
Group Basic Program Setup
Units 0.1 A
Minimum Value 0.0
Maximum Value Drive rated amps x 2
Default Value Based on Drive Rating
Minimum Freq
Sets the lowest frequency the drive will output continuously. Parameter Number 134
Related Parameters
101, 102, 113, 135, 210, 212,
215
Access Rule GET/SET
Data Type UINT
Group Basic Program Setup
Units 0.1 Hz
Minimum Value 0.0
Maximum Value 240
Default Value 0.0
Stop drive before changing this parameter.
Stop drive before changing this parameter.
