D-12 Bulletin 284 CIP Information
Table D.32 Logic Command
Power Flex Native Produced Assembly
Instance 171 is the Power Flex Native Format Produced Assembly.
Table D.33 Instance 171 — PowerFlex Native Format Produced Assembly
Accel 2 Accel 1 Description
0 0 No Command
0 1 Accel 1 Enable
1 0 Accel 2 Enable
1 1 Hold Accel Rate Selected
Decel 2 Decel 1
0 0 No Command
0 1 Decel 1 Enable
1 0 Decel 2 Enable
1 1 Hold Decel Rate Selected
Freq Select 3 Freq Select 2 Freq Select 1
0 0 0 No Command
0 0 1 Freq Source = P136 (Start Source)
0 1 0 Freq Source = P169 (Internal Freq)
0 1 1 Freq Source = Comms
1 0 0 P170 (Preset Freq 0)
1 0 1 P171 (Preset Freq 1)
1 1 0 P172 (Preset Freq 2)
1 1 1 P173 (Preset Freq 3)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Faulted Alarm Deceling Acceling Rot Fwd
Cmd
Fwd
Running Ready
1
Drv In 4
Stat
Drv In 3
Stat
Drv In 2 Stat Drv In 1
Param
Locked
Ctl fm
Net
Ref fm Net At Ref
2 Drive Error Code (low)
3 Drive Error Code (high)
