5 Motor control & motor settings
5.8 Setting the motor parameters for the servo control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.8.3 Motor parameters (object descriptions)
0x2C01 | 0x3401 - Motor: Common parameters
Sub. Name Lenze setting Data type
 1 Motor: Number of pole pairs UNSIGNED_8
 2 Motor: Stator resistance 13.5000 ohms UNSIGNED_32
 3 Motor: Stator leakage inductance 51.000 mH UNSIGNED_32
 4 Motor: Rated speed 4050 rpm UNSIGNED_16
 5 Motor: Rated frequency 270.0 Hz UNSIGNED_16
 6 Motor: Rated power 0.25 kW UNSIGNED_16
 7 Motor: Rated voltage 225 V UNSIGNED_16
 8 Motor: Rated cosine phi 0.80 UNSIGNED_16
 9 Motor: Insulation class 4: F (cut-off temperature = 155 °C) UNSIGNED_8
 10 Motor: Designation STRING(50)
Subindex 1: Motor: Number of pole pairs
Display area (min. value | unit | max. value) Initialisation
0 255
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
Subindex 2: Motor: Stator resistance
Setting range (min. value | unit | max. value) Lenze setting
0.0000 Ohm 125.0000 13.5000 ohms
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10000 UNSIGNED_32
Subindex 3: Motor: Stator leakage inductance
Setting range (min. value | unit | max. value) Lenze setting
0.000 mH 500.000 51.000 mH
 Write access  CINH  OSC  P  RX  TX Scaling: 1/1000 UNSIGNED_32
Subindex 4: Motor: Rated speed
Setting range (min. value | unit | max. value) Lenze setting
0 r/min 50000 4050 rpm
 Write access  CINH  OSC  P  RX  TX UNSIGNED_16
Subindex 5: Motor: Rated frequency
Setting range (min. value | unit | max. value) Lenze setting
0.0 Hz 1000.0 270.0 Hz
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 UNSIGNED_16
Subindex 6: Motor: Rated power
Setting range (min. value | unit | max. value) Lenze setting
0.00 kW 655.35 0.25 kW
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 UNSIGNED_16
