Page 130: 5motor control & motor settings
5
Motor control & motor settings
5.12
Fine adjustment des motor model
130
Lenze · i700 servo inverter · Reference manual · DMS 1.5 EN · 03/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Loading the standard Lh saturation characteristic
If an incorrect Lh saturation characteristic has been determined or none at all, it is possible to load
a device-typical standard Lh characteristic.
How to load the standard Lh saturation characteristic:
1. Set object
(or
• The progress of the procedure is shown in object
for axis B).
2. For permanent storage: After completion of the procedure, upload the Lh saturation
(or
for axis B) to the controller from the i700 servo
inverter.
The »EASY Starter« serves to save the parameter settings of the i700 servo inverter as
parameter file (*.gdc). In the »PLC Designer«, this file can then be imported in the
corresponding axis.
Saving changed parameters safe against mains failure
0x2C07 | 0x3407 - Motor (ASM): Lh saturation characteristic - inductance grid points (y)
Sub.
Name
Lenze setting
Data type
1 Lh: y1 = L01 (x = 0.00 %)
118 %
UNSIGNED_16
2 Lh: y2 = L02 (x = 6.25 %)
118 %
UNSIGNED_16
3 Lh: y3 = L03 (x = 12.50 %)
118 %
UNSIGNED_16
4 Lh: y4 = L04 (x = 18.75 %)
117 %
UNSIGNED_16
5 Lh: y5 = L05 (x = 25.00 %)
116 %
UNSIGNED_16
6 Lh: y6 = L06 (x = 31.25 %)
114 %
UNSIGNED_16
7 Lh: y7 = L07 (x = 37.50 %)
111 %
UNSIGNED_16
8 Lh: y8 = L08 (x = 43.75 %)
107 %
UNSIGNED_16
9 Lh: y9 = L09 (x = 50.00 %)
100 %
UNSIGNED_16
10 Lh: y10 = L10 (x = 56.25 %)
93 %
UNSIGNED_16
11 Lh: y11 = L11 (x = 62.50 %)
86 %
UNSIGNED_16
12 Lh: y12 = L12 (x = 68.75 %)
78 %
UNSIGNED_16
13 Lh: y13 = L13 (x = 75.00 %)
71 %
UNSIGNED_16
14 Lh: y14 = L14 (x = 81.25 %)
64 %
UNSIGNED_16
15 Lh: y15 = L15 (x = 87.50 %)
57 %
UNSIGNED_16
16 Lh: y16 = L16 (x = 93.75 %)
50 %
UNSIGNED_16
17 Lh: y17 = L17 (x = 100.00 %)
42 %
UNSIGNED_16
Write access CINH OSC P RX TX
