0x2944 Torque: Notch filter torque setpoint
1: Notch filter 1: Frequency
UNSIGNED_16 1/10 P
2: Notch filter 1: Bandwidth UNSIGNED_16 1/10 P
3: Notch filter 1: Damping UNSIGNED_8 - P
4: Notch filter 2: Frequency UNSIGNED_16 1/10 P
5: Notch filter 2: Bandwidth UNSIGNED_16 1/10 P
6: Notch filter 2: Damping UNSIGNED_8 - P
0x2945 Torque: Jerk limitation setpoint UNSIGNED_16 1/10 P
0x2946 Cyclic sync torque mode: Speed limitation
1: Speed limitation: Upper speed limit
INTEGER_32 480000/2 31 P OSC Rx
2: Speed limitation: Lower speed limit INTEGER_32 480000/2 31 P OSC Rx
0x2947 Inverter characteristic: Voltage grid points (y)
1: IC: y1 = U01 (x = 0.00 %)
UNSIGNED_16 1/100 P
2: IC: y2 = U02 (x = 6.25 %) UNSIGNED_16 1/100 P
3: IC: y3 = U03 (x = 12.50 %) UNSIGNED_16 1/100 P
4: IC: y4 = U04 (x = 18.75 %) UNSIGNED_16 1/100 P
5: IC: y5 = U05 (x = 25.00 %) UNSIGNED_16 1/100 P
6: IC: y6 = U06 (x = 31.25 %) UNSIGNED_16 1/100 P
7: IC: y7 = U07 (x = 37.50 %) UNSIGNED_16 1/100 P
8: IC: y8 = U08 (x = 42.75 %) UNSIGNED_16 1/100 P
9: IC: y9 = U09 (x = 50.00 %) UNSIGNED_16 1/100 P
10: IC: y10 = U10 (x = 56.25 %) UNSIGNED_16 1/100 P
11: IC: y11 = U11 (x = 62.50 %) UNSIGNED_16 1/100 P
12: IC: y12 = U12 (x = 68.75 %) UNSIGNED_16 1/100 P
13: IC: y13 = U13 (x = 75.00 %) UNSIGNED_16 1/100 P
14: IC: y14 = U14 (x = 81.25 %) UNSIGNED_16 1/100 P
15: IC: y15 = U15 (x = 87.50 %) UNSIGNED_16 1/100 P
16: IC: y16 = U16 (x = 93.25 %) UNSIGNED_16 1/100 P
17: IC: y17 = U17 (x = 100.00 %) UNSIGNED_16 1/100 P
0x2980 Position controller: Gain UNSIGNED_32 1/100 P
0x2981 Position controller: Gain - adaption UNSIGNED_16 1/100 P OSC Rx
0x2982 Position controller: Output signal limitation UNSIGNED_32 480000/2 31 P OSC Rx
0x2983 Position: Select new actual position INTEGER_32 - P OSC Rx
0x2984 Determine target position: Mode UNSIGNED_8 - P
0x29C0 Field controller: Parameter
1: Field controller: Gain
UNSIGNED_32 1/100 P
2: Field controller: Reset time UNSIGNED_16 1/10 P
0x29E0 Field weakening controller: Parameter
1: Field weakening controller: Gain
UNSIGNED_32 1/1000 P
2: Field weakening controller: Reset time UNSIGNED_32 1/10 P
0x29E1 Field set value limitation UNSIGNED_16 1/100 P OSC Rx
0x29E2 DC link circuit voltage: Filter time UNSIGNED_16 1/10 P
0x29E3 Motor voltage act. value: Filter time UNSIGNED_16 1/10 P
0x29E4 Voltage reserve range UNSIGNED_8 - P
Axis A - V/f operation
0x2B00 VFC: V/f characteristic - shape UNSIGNED_8 - P CINH
0x2B01 VFC: V/f characteristic - define reference point
1: VFC: V/f characteristic - voltage at reference point
UNSIGNED_16 - P
2: VFC: V/f characteristic - frequency at reference point UNSIGNED_16 - P
Index Name Data type Scaling Attributes
Greyed out = read only
