3 Communication with the controller
3.2 Process data (cyclic PDO transfer) and PDO mapping
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.2.1 Synchronisation with "Distributed clocks" (DC)
The "Distributed clocks" (DC) function enables an exact time adjustment for applications where
several auxiliary axes carry out a coordinated movement at the same time. The data is accepted
synchronously with the PLC program. In the case of the DC synchronisation, all slaves are
synchronised with a reference clock, called the "DC master".
Object Info
Axis A Axis B
RPDO mapping – configuration of the process data (setpoints) from the controller to the i700 servo inverter
0x1600
0x1610 Fixed, preconfigured PDO mapping object for " Cyclic sync position mode (csp) "
0x1601 0x1611 Fixed, preconfigured PDO mapping object for " Cyclic sync torque mode (cst) "
0x1602 0x1612 Fixed, preconfigured PDO mapping object for " Cyclic sync velocity mode (csv) "
0x1603 0x1613 Fixed, preconfigured PDO mapping object for " Velocity mode (vl) "
0x1604 0x1614 Fixed, preconfigured PDO mapping object for " Touch probe (TP) "
0x1605 0x1615 Freely configurable PDO mapping object
0x1606 0x1616 Fixed, preconfigured PDO mapping object for torque limit values
TPDO mapping – configuration of process data (actual values) from the i700 servo inverter to the controller
0x1A00
0x1A10 Fixed, preconfigured PDO mapping object for " Cyclic sync position mode (csp) "
0x1A01 0x1A11 Fixed, preconfigured PDO mapping object for " Cyclic sync torque mode (cst) "
0x1A02 0x1A12 Fixed, preconfigured PDO mapping object for " Cyclic sync velocity mode (csv) "
0x1A03 0x1A13 Fixed, preconfigured PDO mapping object for " Velocity mode (vl) "
0x1A04 0x1A14 Fixed, preconfigured PDO mapping object for " Touch probe (TP) "
0x1A05 0x1A15 Freely configurable PDO mapping object

"EtherCAT control technology" communication manual
Here you will find some detailed information about DC synchronisation.
