9 Diagnostics & error management
9.4 CiA402 error codes / error messages
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Error code 0x8281: Sync Manager - actual size [value]
Text ID: 0x17
Error code 0x8282: Sync Manager - settings [value]
Text ID: 0x18
Error code 0x8283: PDO Mapping: Object unknown (index [value])
Text ID: 0x2B
Error code 0x8284: No PDO mapping object (index [value])
Text ID: 0x2C
Error code 0x8285: Too many mapped objects (max. number = [value])
Text ID: 0x2D
Error code 0x8286: PDO mapping - error
Text ID: 0x2E
Cause Remedies Response
Incorrect Sync Manager setting of the
EtherCAT master.
• Check the devices on the bus.
• Check cabling or sequence of the
devices on the bus.
• Remove the i700 servo inverter
from the project tree and rescan
the bus.
• Check the device description of
the i700 servo inverter.
Fault
Cause Remedies Response
Incorrect Sync Manager setting of the
EtherCAT master.
• Check the devices on the bus.
• Check cabling or sequence of the
devices on the bus.
• Remove the i700 servo inverter
from the project tree and rescan
the bus.
• Check the device description of
the i700 servo inverter.
Fault
Cause Remedies Response
Unknown index in the PDO mapping. Check PDO mapping. Fault
Cause Remedies Response
Index cannot be mapped as PDO. Check PDO mapping. Fault
Cause Remedies Response
Max. number of PDO mapping
objects has been exceeded (> 64).
Reduce the number of mapping
objects in the "free mapping".
Fault
Cause Remedies Response
Incorrect PDO mapping. Check PDO mapping. Fault
