11 Appendix
11.1 Table of attributes
304
Lenze · i700 servo inverter · Reference manual · DMS 1.5 EN · 03/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Axis B - pole position identification
0x3460 Monitoring pole position identification: Response UNSIGNED_8 - P
0x3461 Pole position identification PPI (360°)
1: PPI (360°): Current amplitude
UNSIGNED_16 - P CINH
2: PPI (360°): Ramp time UNSIGNED_16 - P CINH
3: PPI (360°): Direction of rotation UNSIGNED_8 - P CINH
4: PPI (360°): Fault tolerance UNSIGNED_8 - P
5: PPI (360°): Absolute current amplitude UNSIGNED_32 1/100
0x3462 Pole position identification PPI (min. movement)
1: PPI (min. movement): Current amplitude
UNSIGNED_16 - P CINH
2: PPI (min. movement): Ramp time - current UNSIGNED_16 - P CINH
3: PPI (min. movement): Gain UNSIGNED_16 - P
4: PPI (min. movement): Reset time UNSIGNED_16 1/10 P
5: PPI (min. movement): Max. move permitted UNSIGNED_8 - P
6: PPI (min. movement): Absolute current amplitude UNSIGNED_32 1/100
0x3463 Pole position identification PPI (without movement)
1: Behaviour after switch-on
UNSIGNED_8 - P CINH
Axis B - touch probe
0x3500 Touch probe (TP): Dead time compensation
1: Dead time compensation: TP1 delay time
UNSIGNED_16 1/1000 P
2: Dead time compensation: TP2 delay time UNSIGNED_16 1/1000 P
0x3501 Touch probe (TP): Time stamp
1: TP1: Time stamp - rising edge
UNSIGNED_32 - OSC Tx
2: TP1: Time stamp - falling edge UNSIGNED_32 - OSC Tx
3: TP2: Time stamp - rising edge UNSIGNED_32 - OSC Tx
4: TP2: Time stamp - falling edge UNSIGNED_32 - OSC Tx
Axis B - monitoring functions
0x3540 Ixt utilisation
1: Power stage utilisation (Ixt): Actual utilisation
UNSIGNED_16 - OSC Tx
2: Power stage utilisation (Ixt): Warning threshold UNSIGNED_16 - P
3: Power stage utilisation (Ixt): Error threshold UNSIGNED_16 -
4: Device utilisation (Ixt): Actual utilisation UNSIGNED_16 - OSC Tx
5: Device utilisation (Ixt): Warning threshold UNSIGNED_16 - P
6: Device utilisation (Ixt): Error limit UNSIGNED_16 -
0x3544 Motor speed monitoring
1: Motor speed monitoring: Threshold
UNSIGNED_16 - P
2: Motor speed monitoring: Response UNSIGNED_8 - P
0x3545 Motor phase failure detection
1: Motor phase failure 1: Response
UNSIGNED_8 - P
2: Motor phase failure 1: Current threshold UNSIGNED_8 1/10 P
3: Motor phase failure 1: Voltage threshold UNSIGNED_16 1/10 P
4: Motor phase failure 2: Response UNSIGNED_8 - P
0x3546 Monitoring: Ultimate motor current
1: Ultimate motor current: Threshold
UNSIGNED_16 1/10 P
2: Ultimate motor current: Response UNSIGNED_8 - P
Index Name Data type Scaling Attributes
Greyed out = read only
