Lenze · i700 servo inverter · Reference manual · DMS 1.5 EN · 03/2014 · TD05
287
10 Service/internal
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x2DDC | 0x35DC - Slip: Actual slip
0x2DDD | 0x35DD - Device: Actual output frequency
0x2DDE | 0x35DE - motor: Actual position of rotor angle
Subindex 3: Q-current controller: output signal
Display area
(min. value | unit | max. value)
Initialisation
-3276.7 V 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 4: D-voltage (magnetisation)
Display area (min. value | unit | max. value) Initialisation
-3276.7 V 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 5: Q-voltage (torque)
Display area (min. value | unit | max. value) Initialisation
-3276.7 V 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Display area (min. value | unit | max. value) Initialisation
-3276.7 Hz 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Display area
(min. value | unit | max. value)
Initialisation
-3276.7 Hz 3276.7 0.0 Hz
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Display area
(min. value | unit | max. value)
Initialisation
0 2047
 Write access  CINH  OSC  P  RX  TX INTEGER_16
