Lenze · i700 servo inverter · Reference manual · DMS 1.5 EN · 03/2014 · TD05
243
8
Monitoring functions
8.4
Monitoring of the motor utilisation (I²xt)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x2D4C | 0x354C - Motor utilisation (I²xt): Parameter for the thermal model
Calculation with only one time constant
If k1 = "0 %" is set, the part of the winding is not taken into consideration and the thermal model is
only calculated using the time constant set for the housing/laminated core. This setting is e.g.
required if only the time constant of the laminated core (T2) is known.
Sub.
Name
Lenze setting
Data type
Motor utilisation (I²xt): Thermal time constant
- winding
60 s
UNSIGNED_16
Motor utilisation (I²xt): Thermal time constant
- laminations
852 s
UNSIGNED_16
Motor utilisation (I²xt): Influence of the
winding
27 %
UNSIGNED_8
Motor utilisation (I²xt): Starting value
0 %
UNSIGNED_16
Subindex 1:
Motor utilisation (I²xt): Thermal time constant of the winding
Setting range
(min. value | unit | max. value)
Lenze setting
1
s
36000 60 s
Write access CINH OSC P RX TX
UNSIGNED_16
Subindex 2:
Motor utilisation (I²xt): Thermal time constant - laminated core
Setting range
(min. value | unit | max. value)
Lenze setting
1
s
36000 852 s
Write access CINH OSC P RX TX
UNSIGNED_16
Subindex 3:
Motor utilisation (I²xt): Influence of the winding
Setting range
(min. value | unit | max. value)
Lenze setting
0
%
100 27 %
Write access CINH OSC P RX TX
UNSIGNED_8
Subindex 4:
Motor utilisation (I²xt): Starting value
Setting range
(min. value | unit | max. value)
Lenze setting
0
%
250 0 %
Write access CINH OSC P RX TX
UNSIGNED_16
