Lenze · i700 servo inverter · Reference manual · DMS 1.5 EN · 03/2014 · TD05
251
8
Monitoring functions
8.5
Motor temperature monitoring
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
-3276.8
°C
3276.7 155.0 °C
Write access CINH OSC P RX TX
Scaling: 1/10
INTEGER_16
Subindex 5:
Motor temperature monitoring: Actual motor temperature
Display of the current motor temperature
Display area
(min. value | unit | max. value)
Initialisation
-666.0
°C
666.0
Write access CINH OSC P RX TX
Scaling: 1/10
INTEGER_16
Subindex 6:
Spec. charact.: temperature sampling point 1
From version 01.03
The special thermal sensor characteristic is selected by setting "3" in
for axis B)
Setting range
(min. value | unit | max. value)
Lenze setting
0.0
°C
255.0 25.0 °C
Write access CINH OSC P RX TX
Scaling: 1/10
INTEGER_16
Subindex 7:
Spec. charact.: temperature sampling point 2
From version 01.03
The special thermal sensor characteristic is selected by setting "3" in
for axis B)
Setting range
(min. value | unit | max. value)
Lenze setting
0.0
°C
255.0 150.0 °C
Write access CINH OSC P RX TX
Scaling: 1/10
INTEGER_16
Subindex 8:
Spec. charact.: resistance sampling point 1
From version 01.03
The special thermal sensor characteristic is selected by setting "3" in
for axis B)
Setting range
(min. value | unit | max. value)
Lenze setting
0
Ohm
30000 1000 Ohm
Write access CINH OSC P RX TX
INTEGER_16
Subindex 9:
Spec. charact.: resistance sampling point 2
From version 01.03
The special thermal sensor characteristic is selected by setting "3" in
for axis B)
Setting range
(min. value | unit | max. value)
Lenze setting
0
Ohm
30000 2225 Ohm
Write access CINH OSC P RX TX
INTEGER_16
Subindex 4:
Motor temperature monitoring: Error threshold
