5 Motor control & motor settings
5.14 Parameterising the V/f characteristic control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
The actual flying restart process can be adjusted via the following parameters:
0x2BA1 | 0x33A1 - Flying restart: Current
0x2BA2 | 0x33A2 - Flying restart: Start frequency
0x2BA3 | 0x33A3 - Flying restart: Integration time
0x2BA4 | 0x33A4 - Flying restart: Min. deviation
Current injected in the motor by the flying restart algorithm to identify the current speed.
• Selection in [%] based on the rated motor current ( 0x6075 or 0x6875 for axis B).
• The higher the current the higher the torque imposed upon the motor.
• If the current is too low, a wrong speed can be detected.
Setting range (min. value | unit | max. value) Lenze setting
0 % 100 15 %
 Write access  CINH  OSC  P  RX  TX UNSIGNED_16
Start frequency of the flying restart algorithm
• If it can be anticipated at which frequency the motor "caught" most frequently in a flying restart process, this
frequency is to be set here.
Setting range
(min. value | unit | max. value)
Lenze setting
-600.0 Hz 600.0 20.0 Hz
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Integration time of the angle controller
• The Lenze setting is adapted to machines with an average power.
• A guide value for the integration time can be calculated as a function of the motor power with the following
equation: Ti = 1.1 μ/W * rated motor power + 9.4 ms
• For accelerating the search process, this guide value can be reduced.
• If the flying restart frequency oscillates too much, the integration time has to be increased again.
• A longer integration time increases the time for "catching" the drive.
Setting range (min. value | unit | max. value) Lenze setting
1 ms 60000 600 ms
 Write access  CINH  OSC  P  RX  TX UNSIGNED_16
Setting range (min. value | unit | max. value) Lenze setting
0.00 ° 90.00 5.00 °
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 UNSIGNED_16
