Page 202: 7cia402 device profile
7
CiA402 device profile
7.8
Cyclic sync position mode (csp)
202
Lenze · i700 servo inverter · Reference manual · DMS 1.5 EN · 03/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.8
Cyclic sync position mode (csp)
This operating mode provides a quick position follower with speed/torque/feed force feedforward
control. The motion profile to be processed is defined by the controller.
Subfunctions of the operating mode
• Calculation of the position setpoint
• Calculation of the speed feedforward control value
• Calculation of the speed feedforward control value
• Interpolation between communication cycle and control cycle
• Position control
• Speed control
• Torque control
• Update of the actual values for position, speed, and torque
Selection of the operating mode
"Cyclic sync position mode" is selected with the setting "8" in
(or
for axis B).
Note!
This operating mode can only be actuated reasonably by the use of a servo control.
