7
CiA402 device profile
7.11
Touch probe (TP)
226
Lenze · i700 servo inverter · Reference manual · DMS 1.5 EN · 03/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.11
Touch probe (TP)
A "Touch probe" (short: "TP") is an event which can for instance be actuated in an edge-controlled
manner via a digital input to detect an actual value (that changes quickly) at the time of activation
and to process it further within the program afterwards.
• Typical touch probe applications:
• Homing
• Mark synchronisation
• Measurements of lengths
• Up to 2 touch probe channels can be used in parallel for each axis.
• Possible touch probe sources:
• TP1 : Zero pulse position encoder or digital input DI1
• TP2 : Zero pulse position encoder or digital input DI2
Objects described in other chapters:
Objects described in this chapter:
Note!
The digital inputs DI1 and DI2 can be evaluated additionally as "normal" digital inputs
object any time (or
for axis B).
Object
Name
Data type
Axis A
Axis B
Digital inputs
UNSIGNED_32
Greyed out = read access only
Object
Name
Data type
Axis A
Axis B
Lenze-specific objects
Touch probe (TP): Filter time
UNSIGNED_16
Touch probe (TP): Delay time
RECORD
Touch probe (TP): Time stamp
RECORD
Objects according to CiA402 specification (version 3)
Touch probe function
UNSIGNED_16
Touch probe status
UNSIGNED_16
Touch probe pos1 pos value
INTEGER_32
Touch probe pos1 neg value
INTEGER_32
Touch probe pos2 pos value
INTEGER_32
Touch probe pos2 neg value
INTEGER_32
Greyed out = read access only
