0x2C06 Motor (SM): Magnet characteristic (current) - grid points
1: Magnet characteristic: x1 = i01/iN
UNSIGNED_16 - P
2: Magnet characteristic: y1 = kT01/kTN UNSIGNED_16 - P
3: Magnet characteristic: x2 = i02/iN UNSIGNED_16 - P
4: Magnet characteristic: y2 = kT02/kTN UNSIGNED_16 - P
5: Magnet characteristic: x3 = i03/iN UNSIGNED_16 - P
6: Magnet characteristic: y3 = kT03/kTN UNSIGNED_16 - P
7: Magnet characteristic: x4 = i04/iN UNSIGNED_16 - P
8: Magnet characteristic: y4 = kT04/kTN UNSIGNED_16 - P
0x2C07 Motor (ASM): Lh saturation characteristic - inductance grid points (y)
1: Lh: y1 = L01 (x = 0.00 %)
UNSIGNED_16 - P
2: Lh: y2 = L02 (x = 6.25 %) UNSIGNED_16 - P
3: Lh: y3 = L03 (x = 12.50 %) UNSIGNED_16 - P
4: Lh: y4 = L04 (x = 18.75 %) UNSIGNED_16 - P
5: Lh: y5 = L05 (x = 25.00 %) UNSIGNED_16 - P
6: Lh: y6 = L06 (x = 31.25 %) UNSIGNED_16 - P
7: Lh: y7 = L07 (x = 37.50 %) UNSIGNED_16 - P
8: Lh: y8 = L08 (x = 43.75 %) UNSIGNED_16 - P
9: Lh: y9 = L09 (x = 50.00 %) UNSIGNED_16 - P
10: Lh: y10 = L10 (x = 56.25 %) UNSIGNED_16 - P
11: Lh: y11 = L11 (x = 62.50 %) UNSIGNED_16 - P
12: Lh: y12 = L12 (x = 68.75 %) UNSIGNED_16 - P
13: Lh: y13 = L13 (x = 75.00 %) UNSIGNED_16 - P
14: Lh: y14 = L14 (x = 81.25 %) UNSIGNED_16 - P
15: Lh: y15 = L15 (x = 87.50 %) UNSIGNED_16 - P
16: Lh: y16 = L16 (x = 93.75 %) UNSIGNED_16 - P
17: Lh: y17 = L17 (x = 100.00 %) UNSIGNED_16 - P
0x2C08 Motor: Motor parameter setting method UNSIGNED_8 - P
Axis A - feedback system
0x2C40 Encoder: Type UNSIGNED_8 - P CINH
0x2C41 Hiperface: Parameter
1: Hiperface: Determined type code
UNSIGNED_8 -
2: Hiperface: User def. encoder - type code UNSIGNED_8 - P CINH
3: Hiperface: User def. encoder - specifiable revolutions UNSIGNED_16 - P CINH
4: Hiperface absolute value fault: Response UNSIGNED_8 - P
5: Hiperface: Serial number STRING(50) -
6: Hiperface: Raw data - Actual position UNSIGNED_32 - OSC Tx
7: Hiperface: Detected Increments / revolution UNSIGNED_16 - Tx
8: Hiperface: Type code supported by firmware UNSIGNED_8 - Tx
9: Hiperface: Encoder type UNSIGNED_8 - Tx
10: Hiperface: Period length of linear encoders UNSIGNED_32 - Tx
0x2C42 Encoder: Parameter
1: Encoder: Increments / revolution
UNSIGNED_32 - P CINH
2: Encoder: Supply voltage UNSIGNED_8 1/10 P CINH
3: Encoder: Angle drift - Actual angle error INTEGER_16 1/10 OSC Tx
4: Encoder: Signal quality - Actual amplitude UNSIGNED_8 - OSC
0x2C43 Resolver: Number of pole pairs UNSIGNED_8 - P CINH
0x2C44 Resolver error compensation: Parameter
1: Resolver error compensation: Angle
INTEGER_16 - P
2: Resolver error compensation: Cosine track gain UNSIGNED_16 - P
3: Resolver error compensation: Sine track gain UNSIGNED_16 - P
Index Name Data type Scaling Attributes
Greyed out = read only
