Commissioning
Quick stop (QSP)
6
l
243 EDBCSXP064 EN 8.0
6.28 Quick stop (QSP)
During the process, a quick stop (QSP) can be actuated via the control word Ctrl1 with
control bit Ctrl1.QSP = 1, i. e. the drive brakes to standstill along the QSP deceleration time
set (C0105) and a change to the "Stand−by" state is effected (status bit Stat2.QspIn = 1).
The quick stop deceleration time is set with C0105 in the GDC parameter menu under
Positioning/E−Shaft
W Positioning behaviour.
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.} Selection
C0042 DIS: QSP Quick stop status (QSP)
Only display ^ 243
0 QSP not active
1 QSP active
C0105 QSP Tif 0.0 Deceleration time for quick stop
(QSP) ^ 243
0.000 {0.001 s} 999.999 Relating to speed variation n
max
(C0011) ...0 rev./min.
