Appendix – Lenze ECSCPxxx User Manual
Page 388

Appendix
Code table
l
388
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C2102 Task switch
0
Change−over:
System task
àcycl. task (PLC)
0
Time slice
No change−over
1
Time slice + end of PLC_PRG
2
Time slice + end of PLC_PRG + end of
system task
C2104 PLC Autorun
(Posi & Shaft)
1
Automatic start of PLC program
after power−up
0
Off
1
On
C2106 Downl.protect
0
Write protection of PLC program
0
Inactive
1
Active
2
Reserved
C2108 PLC run/stop
(Posi & Shaft)
2
{1}
PLC programcontrol
0
No function
1
Run
2
Stop
3
Reset
C2111 GDC Id
27012006132510 =
l
Date (day.month.year): 27.01.2006
l
Time (h:min:sec): 13:25:10
Creation date of PLC program
Read only
C2113 PLC Prog
Name
Name of PLC program
Read only
C2115 T−Fkt Credit
0
Number of technology units
C2116 CreditPinCode
0
Code for technology units if
service is required (please
consult Lenze)
0
{1}
4294967295
C2117 Full Credit
0
Service code
C2118 ParWriteChan
.
0
CAN object for L_ParRead and
L_ParWrite
(byComChannel = 10)
^ 289
0
Unused PDO channel free for
reconfiguration
(CAN1...3_IN/CAN1...3_OUT)
1
Parameter data channel 2
C2120 AIF: Control
0
AIF−CAN: control word
0
{1}
255 Binary interpretation reflects bit
states
0
No command
Note: The MSB (bit 7) of the
control word automatically
changes its state with every
access to the code. Observe this
when interpreting the data!
1
Read XCAN codes + reinitialisation
2
Read XCAN code
10
Read XCAN C2356/1 ... 4
11
Read XCAN C2357
12
Read XCAN C2375
13
Read XCAN C2376 ... C2378
14
Read XCAN C2382
255
Not assigned
