Configuration
Configuring MotionBus/system bus (CAN)
Setting of boot−up time/cycle time
l
274
EDBCSXP064 EN 8.0
8.1.4
Setting of boot−up time/cycle time
Boot−up time (C0356/1, C2456/1) setting
In a CAN network without higher−level control (PLC), a bus node (boot−up master) has to
initialise the CAN network. If the 24 V low−voltage supply is switched on, the boot−up time
elapses. After the boot−up time has elapsed, the NMT telegram for initialising the CAN
network is sent by the boot−up master and the process data transfer is started.
ƒ
Only valid if C0352/C2452 = 1 (master).
ƒ
Normally the Lenze setting (3000 ms) is sufficient.
ƒ
State change from "Pre−operational" to "Operational"
Cycle time for process output data (C0356/2...3, C2456/2)
Transmission cycle time for the process data objects CAN2...3_OUT (C0356/2...3) or
CANaux2_OUT (C2456/2) in cyclic operation (without sync)
ƒ
Setting "0" = event−controlled data transmission
The output data will only be sent if a value in the output object changes.
Activation delay for process output data (C0356/4, C2456/4)
Delay time for initial transmission of the process data object CAN2...3_OUT (C0356/4) or
CANaux2_OUT (C2456/4) after the CAN bus changes from NMT "Pre−Operational" state to
"Operational"".
After the delay time has elapsed, the process data objects CAN2...3_OUT or CANaux2_OUT
will be sent for the first time.
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0356
CAN time settings for CAN bus
interface X4
^ 274
1 CAN times
3000
0
{1 ms}
65000 CAN boot−up time:
Delay time after mains
connection for initialisation
through the master.
2 CAN times
0
CAN2...3_OUT cycle times:
Factor for the task time to send
process data telegram.
0 = event−controlled
transmission
3 CAN times
0
4 CAN times
20
Delay time for initial
transmission of the process data
objects 2 and 3 after the CAN bus
changed to "Operational"
