Appendix – Lenze ECSCPxxx User Manual
Page 386

Appendix
Code table
l
386
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C1121 Sync cycle
2
Synchronisation cycle
^ 278
1
{1 ms}
13
C1122 Sync phase
0.460
Synchronisation phase
^ 278
0.000
{0.001 ms}
6.500
C1123 Sync window
0.010
Synchronisation window
l
When the sync
telegram/signal transmitted
by the master is within this
"time slot", the status bit
Stat2.CANSyncInWin switches
to TRUE.
0.000
{0.001 ms}
6.500
C1190 MPTC mode
0
Selection of PTC motor
temperature sensor
characteristic
0
Characteristic for PTC 83−110 (Lenze
standard)
1
Can be specifically set by the user
under C1191 and C1192
2
Characteristic for PTC 83−110 and 2 x
PTC150 (e.g. in MCS motors)
This selection is only available as
of operating system V 8.0. For
the corresponding motors, the
parameter is not automatically
transferred into GDC by the
motor data assistant. The
parameter has to be set later!
C1191
Selection of temperature
characteristic for PTC
1 Char.: temp
25
0
{1
°C}
255 PTC characteristic:
lower temperature T1
2 Char.: temp
150
PTC characteristic:
upper temperature T2
C1192
Selection of resistance
characteristic for PTC
1 Char.: OHM
1000
{0}
0
{1
W}
30000 PTC characteristic:
resistance R1 at T1
2 Char.: OHM
2225
PTC characteristic:
resistance R2 at T2
C1200 Fdbk rat num
1
Feedback of gearbox factor
numerator
l
The gearbox ratio (i) specifies
the number of revolutions of
the motor axis at which the
encoder axis revolves exactly
once.
l
i = Z2 / Z1 (ratio of the
number of teeth or
circumferences)
l
i = n1 / n2 (ratio of the
speeds)
1
{1}
65535
C1201 Fdbk rat den
1
Feedback of gearbox factor
denominator
1
{1}
65535
