Appendix – Lenze ECSCPxxx User Manual
Page 391
Appendix
Code table
l
391
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C2367 Sync Rx Id
128
XCAN receive identifier of the
sync telegram(AIF interface X1)
1
{1}
2047
C2368 Sync Tx Id
128
XCAN send identifier of the sync
telegram
(AIF interface X1)
1
{1}
2047
C2373
XCAN Sync counter
(AIF interface X1)
1 Sync Rate IN
1
1
{1}
240 XCAN1_IN
2 Sync Rate IN
1
XCAN2_IN
3 Sync Rate IN
1
XCAN3_IN
C2374
XCAN Sync counter
(AIF interface X1)
1 Sync Rate OUT
1
1
{1}
240 XCAN1_OUT
2 Sync Rate OUT
1
XCAN2_OUT
3 Sync Rate OUT
1
XCAN3_OUT
C2375
TX mode for XCANx_OUT
(AIF interface X1)
1 XCAN Tx
mode
0
Response to sync
XCAN1_OUT
2 XCAN Tx
mode
0
Response to sync
XCAN2_OUT
3 XCAN Tx
mode
0
Response to sync
XCAN3_OUT
0
Response to sync
1
No response to sync
2
Event
3
Event, cycle C2356 superimposed
C2376
XCAN1_OUT mask
(AIF interface X1)
1 XCAN1 Mask
FFFF
0000
{hex}
FFFF Mask for process data output
word 1
2 XCAN1 Mask
FFFF
Mask for process data output
word 2
3 XCAN1 Mask
FFFF
Mask for process data output
word 3
4 XCAN1 Mask
FFFF
Mask for process data output
word 4
C2377
XCAN2_OUT mask
(AIF interface X1)
1 XCAN2 Mask
FFFF
0000
{hex}
FFFF Mask for process data output
word 1
2 XCAN2 Mask
FFFF
Mask for process data output
word 2
3 XCAN2 Mask
FFFF
Mask for process data output
word 3
4 XCAN2 Mask
FFFF
Mask for process data output
word 4
