Commissioning
Operation with motors from other manufacturers
Effecting rotor position adjustment
l
251
EDBCSXP064 EN 8.0
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0058 Rotor diff
−90.0
Rotor displacement angle (offset
angle)
Input in case of Lenze motor with
l
resolver: −90°
l
hiperface absolute value
encoder: 0°
Code value is adapted by the
rotor position adjustment
function (C0095).
Only relevant for the operation
of synchronous motors.
^ 249
−180.0
{0.1
_}
179.9
[C0095] Rotor pos adj
0
Activation of rotor position
adjustment for automatic
determination of the rotor
displacement angle.
C0058 displays the determined
rotor displacement angle (offset
angle).
^ 249
0
Inactive
1
Active
