Process data to the axis module (control word Ctrl1 and setpoints)
Process data is transmitted cyclically to the drive via the control interface set under C4010
with a data width of 8 bytes or 4 words.
The telegram structure of the 8 byte process data to the drive is the same for all selectable
control interfaces. In addition to the control word Ctrl1 (Word 1), Word 2, Word 3 and Word
4 are available for setpoints.
Control bit 15 of the control word Ctrl1 serves to set the assignment of the words 2 ... 4.
Assignment of the process data to the drive:
Word 1
Word 2
DWord (word 3 + word 4)
LOW byte HIGH byte LOW byte HIGH byte
LOW word
HIGH word
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
Ctrl1.Bit15 = 0
Control word
Ctrl1
rx_par1
rx_par2
rx_par3
Ctrl1.Bit15 = 1
VelDirect
PosDirect
