Configuration
Remote parameterisation (gateway function)
l
289
EDBCSXP064 EN 8.0
8.4
Remote parameterisation (gateway function)
From operating system V6.x onwards, the axis module supports the remote
parameterisation of other fieldbus nodes. Then, all write/read accesses to parameters are
not executed anymore in the axis module but redirected to the bus node selected for
remote maintenance.
ƒ
The redirection takes place via the parameter data channel SDO1 of the selected
node.
ƒ
The node to which the write/read accesses is to be redirected, is determined with
the corresponding node address via C0370.
(C0370 = 0: remote parameterisation deactivated)
ƒ
The gateway channel of the axis module is selected via C0371 (interface X4 (CAN) or
interface X14 (CAN−AUX)).
ƒ
C2118 (CAN) or C2470 (CAN−AUX) serves to select the transmission channel for
reading and writing the parameter data.
ƒ
A timeout during remote parameterisation activates the system error message
"CE5" (CAN) or "CE15" (CAN−AUX). The corresponding response can be configured
under C0603/C2485 (
¶ 299).
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
[C0370] SDO gateway
0
Activate address
gateway/remote
parameterisation
l
C0370
¹ 0: All code
write/read accesses are
redirected to the CAN node
with the CAN node address
set here.
l
The corresponding code is
accessed via parameter data
channel 1 of the target device.
l
C0370 = 0: remote
parameterisation is
deactivated
^ 289
0
{1}
63
C0371 Gateway Ch.
1
Selection of the gateway channel
^ 289
0
CAN
Use CAN bus interface X4
1
CAN−AUX
Use CAN bus interface X14
C0603 MONIT CE5
3
Fault response − gateway
function monitoring (CE5)
"Timeout" when remote
parameter setting (C0370) is
activated via interface X4 (CAN)
^ 297
^ 289
0
TRIP
2
Warning
3
Off
