Commissioning
Setting of the feedback system for position and speed control
Absolute value encoder as position and speed encoder
l
149
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
[C0427] Enc. signal
0
Function of the master frequency
input signals on X8 (DFIN)
^ 136
^ 145
0
2−phase
1
A: speed
B: direction
2
A or B: speed or direction
[C0491] X8 in/out
0
Function of X8
^ 132
0
X8 is input
Use as encoder feedback or
master frequency input for
positioning profile mode
C3095/x = 30 (electrical shaft
with setpoint via X8)
1
X8 is output
Use as encoder feedback or
master frequency output during
master operation (electrical shaft
as setpoint via X8)
C3001 EncDirInv
0
Position encoder mounting
position
0
Normal (direction of rotation CW)
Direction of rotation with regard
to the motor’s direction of
rotation
1
Inverse (direction of rotation CCW)
