Appendix – Lenze ECSCPxxx User Manual
Page 363

Appendix
Code table
l
363
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0150 Status word
0
Device status word for
networking via automation
interface (AIF)
Read only
^ 163
0
{1}
65535 Controller evaluates information
as 16 bits (binary−coded)
Bit 0
Not assigned
Bit 1
Pulse inhibit (IMP)
Bit2
Not assigned
Bit3
Not assigned
Bit4
Not assigned
Bit5
Not assigned
Bit 6
n = 0
Bit 7
Controller inhibit (CINH)
Bit 8
Device status bit 1
Bit 9
Device status bit 2
Bit10
Device status bit 3
Bit11
Device status bit 4
Bit12
Warning
Bit13
Message
Bit14
Not assigned
Bit15
Not assigned
C0155 Status word 2
0
Status word 2 (advanced status
word)
Display only
0
{1}
65535 Controller interprets information
as 16 bit (binary coded)
Bit 0
Active fault
Bit 1
M
max
reached
Bit 2
I
max
reached
Bit 3
Pulse inhibit(IMP)
Bit 4
Ready for operation (RDY)
Bit 5
Controller inhibit (CINH)
Bit 6
TRIP active
Bit 7
Initialisation
Bit 8
Motor direction of rotation (Cw/CCw)
Bit 9
Not assigned
Bit 10
Not assigned
Bit 11
Not assigned
Bit 12
Not assigned
Bit 13
Not assigned
Bit 14
Not assigned
Bit 15
Not assigned
