C3035 DwellTime
50
Dwell time after end of profile
^ 232
0
{1 ms}
65535 Time required from positioning
profile end (setpoint generator
has reached target position) to
the setting of status bit
Stat1.DwellTime = 1
C3036 BounceTime
0
Debounce time for touch probe
input
0
{0.001 ms}
65535
C3040 SW−LimPos
3600.0
Positive software limit position
^ 237
0.0000
{0.0001
units}
214000.0000
C3041 SW−LimNeg
−3600.0
Negative software limit position
^ 237
−214000.0000
{0.0001
units}
0.0000
C3042 SWLimCtrl
Mode
0
Mode of the software limit
position monitoring
0
Current setpoint position +
defined direction of movement
1
Current actual position
C3050 Act. position
Current position in increments
Read only
−2.147.483.647
{1 inc}
2.147.483.647
C3051 Current
position
Current position in units
Read only
−214000.0000
{0.0001
units}
214000.0000 The display is limited to +/−
214000.0000
C3052 Act. profile
l
Control bit
Ctrl1.ProfEnable = 1:
Number of the positioning
profile currently active or
executed last
l
Control bit
Ctrl1.ProfEnable = 1 or 0:
After cancelling the active
profile, the profile number 0
is displayed.
Read only
0
{1}
15
C3053 Current
velocity
Current speed in units/s
Read only
−214000.0000
{0.0001
units/s}
214000.0000
C3056 ActTargetPos
Current target position/distance
in increments (inc)
−2.147.483.647
{1 inc}
2.147.483.647
C3057 TargetPosReal
Current target position/distance
in units
−214000.0000
{0.0001
units}
214000.0000
