Diagnostics
Diagnostics with Global Drive Oscilloscope (GDO)
Diagnostics with GDO
l
332
EDBCSXP064 EN 8.0
Description
Display
format
Display
Code
Signal
type
Data type
Variable
designation
g_MCTRL_bMotorTempGrea
terSetValue_b
Bool
binary
−
−
Monitoring: Motor
temperature > 150 °C
g_MCTRL_bMotorTempGrea
terC0121_b
Monitoring: Motor
temperature > C0121
g_MCTRL_bPtcOverTemp_b
Monitoring: Motor
overtemperature (PTC)
g_MCTRL_bKuehlGreaterSet
Value_b
Monitoring: Heatsink
temperature > 90 °C
g_MCTRL_bKuehlGreaterC01
22_b
Monitoring: Heatsink
temperature > C0122
g_bDigin_bIn1_b
Bool
binary
C0443
bin
Digital inputs
g_bDigin_bIn2_b
g_bDigin_bIn3_b
g_bDigin_bIn4_b
g_bDigin_Save_Standstill_b
Safe torque off (formerly "safe
standstill")
g_bDigout_bOut_b
Bool
binary
C0444/1
bin
Digital output
g_bDigout_bRelais_b
C0444/2
Feedback "safe torque off"
(formerly "safe standstill")
g_nAin_nIn_a
integer
analog
C0400
dec [%]
Analog input
g_nAin_bError_b
Bool
binary
−
−
TRUE if I < 2 mA
