Appendix – Lenze ECSCPxxx User Manual
Page 379

Appendix
Code table
l
379
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0559 SD8 filter t
1
Filter time constant (SD8)
1
{1 ms}
200 Example:
If the setting is "10 ms", a
SD8−TRIP is actuated after 10 ms.
C0576 nErr tolerance
100
Tolerance window for the speed
system deviation referring to
n
max
100 % = lowest monitoring
sensitivity
^ 321
0
{1 %}
100
C0577 Vp fld weak
0.100
Gain of the field weakening
controller (V
p
)
^ 254
0.000
{0.001}
63.999
C0578 Tn fld weak
3.0
Integral−action time of the field
weakening controller (V
n
)
0.1
{0.1 ms}
6000.0
C0579 nErr response
3
Fault response − monitoring of
speed system deviation
^ 321
0
TRIP
1
Message
2
Warning
3
Off
4
FAIL−QSP
C0580 Monit SD8
3
Fault response − monitoring of
SinCos signals at X8
^ 320
0
TRIP
3
Off
C0581 MONIT EEr
0
Fault response − external fault
monitoring "ExternalFault" (EEr)
0
TRIP
1
Message
2
Warning
3
Off
4
FAIL−QSP
C0582 MONIT OH4
2
Setting of the fault response −
monitoring of heatsink
temperature in C0122
^ 303
0
TRIP
2
Warning
3
Off
C0583 MONIT OH3
0
Fault response − monitoring of
motor temperature (fixed
temperature threshold).
Detection through KTY thermal
sensor via resolver input X7 or
encoder input X8.
^ 301
0
TRIP
2
Warning
3
Off
