Commissioning

Basic terms of positioning
Machine parameters

6

l

106

EDBCSXP064 EN 8.0

Maximum target position selection (C4265)

The maximum target position selection results from the possible traversing range of
16384 position encoder revolutions converted into real units.

C4265

+ 16384 [rev.] @ 65536 [incr.ńrev.] @ 10000 @ C1204 @ C1203 @ C1200

65536

@ C1202 @ C1201

C4265 is limited to

±214000.0000 units.

Position resolution (C4266)

Number of increments per unit specified

ƒ

Due to the internal remainder considered, the lowest−order position can vary about
1.

ƒ

1 revolution of position encoder

¢ 65536 increments.

ƒ

Value range: 0 ... 2140000000

Maximum traversing speed (C1240)

Via C1240 you can define the maximum traversing speed (v

max

) for the machine. The

speed specifications in the positioning profiles are limited internally to v

max

. v

max

should

be set lower than the velocity possible at maximum motor speed (C0011). The value can
be calculated according to the following formula:

C1240

v C0011 @ C1204 @ C1203

60

@ C1202

v

max

v n

max

@

v

k

60

@ i

I

Tip!

The maximum input value for v

max

can be read out via C3060.

Maximum acceleration/deceleration (C1250)

The maximum permissible acceleration or deceleration for positioning processes among
other things depends on the motor torque and the moment of inertia of the entire
mechanics driven during the positioning process.
