Commissioning
Operation with motors from other manufacturers
Entering motor data manually
l
245
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0018 fchop
2
Switching frequency
1
4 kHz sin
4 kHz permanent PWM
frequency
2
8/4 kHz sin
8 kHz PWM frequency with
automatic derating to 4 kHz at
high load
C0022 Imax current
à
I
max
limit
0
{0.01 A}
à
Device−dependent list
Max. current can be gathered
from the technical data.
[C0081] Mot power
3.20
Rated motor power according to
nameplate
0.01
{0.01 kW}
500.00
[C0084] Mot Rs
1.10
Stator resistance of the motor
The upper limit is
device−dependent.
0.00
{0.01
W}
95.44 ECSxS/P/M/A004
47.72 ECSxS/P/M/A008
23.86 ECSxS/P/M/A016
11.93 ECSxS/P/M/A032
7.95 ECSxS/P/M/A048
5.96 ECSxS/P/M/A064
[C0085] Mot Ls
5.30
Leakage inductance of the motor
0.00
{0.01 mH}
200.00
[C0087] Mot speed
3700
Rated motor speed
300
{1 rpm}
16000
[C0088] Mot current
7.0
Rated motor current
0.5
{0.1 A}
500.0
[C0089] Mot
frequency
185
Rated motor frequency
10
{1 Hz}
1000
[C0090] Mot voltage
325
Rated motor voltage
50
{1 V}
500
[C0091] Mot cos phi
1.0
cos
j of the asynchronous motor
0.50
{0.01}
1.00
C0128 Tau motor
5.0
Thermal time constant of the
motor
^ 309
0.5
{0.1 min}
25.0 For calculating the I
2
x t
disconnection
C2108 PLC run/stop
(Posi & Shaft)
2
{1}
PLC programcontrol
0
No function
1
Run
2
Stop
3
Reset
