Commissioning
Controller enable (CINH = 0)
l
242
EDBCSXP064 EN 8.0
The following table describes the status displays for the controller inhibit (Cinh) /
controller enable:
Status display
Controller inhibited
Enable controller
Comment
Green LED
Blinking
Constantly ON
C0183 drive
diagnostics
Display of the signal
source for controller
inhibit (Cinh)
Display "OK"
See GDC menu "Diagnostics / Device
current status" or GDC monitor window
down right
C0150 DCTRL status
word Bit 7 (CINH
active)
C0150.Bit07 = 1
C0150.Bit07 = 0
See GDC menu "Diagnostics / display
MCTRL"
Keypad text display
"IMP"
"IMP"
"IMP" not displayed
)
Note!
All signal sources for controller inhibit (Cinh) act like a series connection of
switches which are independent of each other.
