Appendix – Lenze ECSCPxxx User Manual
Page 407

Appendix
Code table
l
407
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C4023 Brk: N_Thresh
0.1 %
Speed threshold for brake
activation
^ 130
0.00
{0.01 %}
10.00
C4040 AppControl
0
Control word to the drive
Only active if C4010 = 3.
^ 158
0
{1}
65535
C4041 App−Rx−W2
0
Data word 2 to the drive
Only active if C4010 = 3.
−32767
{1}
32767
C4042 App−Rx−W3/4
0
Double data word 3/4 to the
drive
Only active if C4010 = 3.
−2147483647
{1}
2147483647
C4045 AppState 1
Status word 1 from the drive
l
Read only
^ 161
0
{1}
65535
C4046 AppState 2
Status word 2 from the drive
l
Read only
^ 161
0
{1}
65535
C4047 App−Tx−W2
0
Data word 2 from the drive
−32767
{1}
32767
C4048 App−Tx−W3
0
Data word 3 from the drive
−32767
{1}
32767
C4049 App−Tx−W3/4
0
Double data word 3/4 from the
drive
−2147483647
{1}
2147483647
C4050 PosProfSel
Number of the selected
positioning profile
Only display
0
{1}
15
C4052 PO: Ctrl (W1)
Currently effective control word
Ctrl1
Read only
0
{1}
65535
C4053 PO: W2
Currently effective VelDirect
value
Read only
−32767
{1}
32767
C4054 PO: W3/4
Currently effective PosDirect
value
Read only
−2147483647
{1}
2147483647
C4060 ES_NOffs
Only for "electrical shaft"
function: default value (in
increments) for
speed−proportional angular
trimming relating to
15000 rev./min.
Note: Only change value when
the controller is at standstill!
^ 235
−655360
{1 inc}
655360
