Monitoring
functions
Overview of monitoring functions
9
l
296
EDBCSXP064
EN 8.0
Possible fault responses
l Lenze setting
ü Can be set
Monitoring
Off
Fail−QSP
Warning
Message
TRIP
Code
Source
Description
Fault message
0072
PR1
Check sum error in parameter set 1
Internal
l
0074
PEr
Program error
Internal
l
0075
PR0
Error in the parameter sets
Internal
l
0079
PI
Error during parameter initialisation
Internal
l
0080
PR6
l
For ECSxS/P/M:Internal fault
l
For ECSxA: Too many user codes
Internal
l
Application−specific fault messages
2402
PosPosLimit Warning: Positive software limit position (C3040) has been reached.
l
2403
NegPosLimi
t
Warning: Negative software limit position (C3041) has been reached.
l
2404
FollowErrW
arn
Warning: Following error tolerance (C3030) has been reached.
l
2422
InvProfData Impermissible positioning profile parameters
l
2423
OverflIntPos Position setpoint overflow
l
2424
SWLimOut−
OfRan
Warning: Impermissible setting of the software limit positions
(C3040/C3041)
l
3400
PosLimitSw
FAIL−QSP: Positive hardware limit switch has been approached.
l
3401
NegLimitSw FAIL−QSP: Negative hardware limit switch has been approached.
l
3402
PosPosLimit FAIL−QSP: Positive software limit position (C3040) has been reached.
l
3403
NegPosLimi
t
FAIL−QSP: Negative software limit position (C3041) has been reached.
l
3405
FollowErrFai
l
FAIL−QSP: Following error tolerance (C3031) has been reached.
l
3406
HomePosErr Home position has not been reached.
l
3409
MaxVelErr
Max. speed in C1240 is set too high.
l
3417
InSftw−
Limits
FAIL−QSP: Impermissible setting of the software limit positions
(C3040/C3041)
l
0425
InvHoming−
Offs
Reference measuring system offset (C3012) is invalid.
l
3500
ExtTripSet
External fault has been triggered.
l
3501
InvTpProfN
o
Invalid positioning profile number with touch probe positioning
l
3503
InvalidFeed
b
Impermissible feedback system selection
l
3504
InvalidOS
Version of operating system is not compatible.
l
x: 0 = TRIP, 1 = message, 2 = warning, 3 = FAIL−QSP
1)
Adjustable in the DDS under Project
W Exceptional handling
2)
For ECSxA... only
