[C0491] X8 in/out
0
Function of X8
^ 132
0
X8 is input
Use as encoder feedback or
master frequency input for
positioning profile mode
C3095/x = 30 (electrical shaft
with setpoint via X8)
1
X8 is output
Use as encoder feedback or
master frequency output during
master operation (electrical shaft
as setpoint via X8)
[C0495] Feedback n
0
Selection of feedback system for
speed control
^ 132
0
Resolver at X7
Standard setting
1
TTL encoder at X8
l
Sets C0419 = 0 ("Common") if
a different encoder type as
under C0419 is set here.
2
SinCos encoder at X8
3
Absolute value encoder (single−turn) at
X8
4
Absolute value encoder (multi−turn) at
X8
C0497 Nact filter
2.0
Time constant of actual speed
value
0.0
{0.1 ms}
50.0 0.0 ms = switched off
C0504 Service codes
Only the Lenze service is allowed
to make changes!
...
C0509
C0510 ProtAppFlash
0
Write−protection application
FLASH
0
No write protection
1
Write protection is active
C0517
User menu with up to 32 entries
1 User menu
51.0
C0051
MCTRL−NACT
Display of actual speed
2 User menu
54.0
C0054
Imot
Display of motor current
3 User menu
(Posi & Shaft)
56.0
C0056
MCTRL−MSET2
Torque setpoint (nMSetIn_a)
{3998.0} C3998
Current fault
Current application fault
4 User menu
(Posi & Shaft)
0.0
{183.0}
C0183
Diagnostics
5 User menu
(Posi & Shaft)
0.0
{4166.0}
C4166
TripAppReset
6 User menu
(Posi & Shaft)
183.0
{2113.0}
C2113
PLC prog name
7 User menu
(Posi & Shaft)
168.01
{22.0}
C0022
Imax current
Input of maximum output
current
8 User menu
(Posi & Shaft)
0.0
{11.0}
C0011
Nmax
Input of the maximum speed
9 User menu
(Posi & Shaft)
22.0
{105.0}
C0105
QSP Tif
Entry of deceleration time for
quick stop (QSP)
10 User menu
(Posi & Shaft)
0.0
{70.0}
C0070
Vp speed CTRL
Input of gain for speed controller
11 User menu
(Posi & Shaft)
11.0
{71.0}
C0071
Tn speed CTRL
Input of integral−action time for
speed controller
12 User menu
(Posi & Shaft)
0.0
{254.0}
C0254
Vpw
MCTRL_MotorControl: phase
controller gain (V
p
)
