Configuration
Configuring MotionBus/system bus (CAN)
Individual addressing
8
l
272 EDBCSXP064 EN 8.0
IMPORTANT Possible settings Code
Selection Lenze/
{Appl.} Designation No.
C0354 Alternative node address for
CAN_IN/CAN_OUT (CAN bus
interface X4) ^ 271
1 CAN addr. 129 1 {1} 512 Address 2 CAN1_IN
2 CAN addr. 1 Address 2 CAN1_OUT
3 CAN addr. 257 Address 2 CAN2_IN
4 CAN addr. 258 Address 2 CAN2_OUT
5 CAN addr. 385 Address 2 CAN3_IN
6 CAN addr. 386 Address 2 CAN3_OUT
C2453 Source for system bus node
addresses of
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
^ 271
1 CANa addr sel 0 CAN node address (C2450) Address CANaux1_IN/OUT
2 CANa addr sel 0 CAN node address (C2450) Address CANaux2_IN/OUT
3 CANa addr sel 0 CAN node address (C2450) Address CANaux3_IN/OUT
0 C2450 (auto) Automatically determined by
C2450
1 C2454 (man.) Determined by C2454
C2454 Alternative node addresses for
CANaux_IN/CANaux_OUT (CAN
bus interface X14) ^ 271
1 CANa addr. 129 1 {1} 512 CANaux1_INaddress 2
2 CANa addr. 1 CANaux1_OUTaddress 2
3 CANa addr. 257 CANaux2_INaddress 2
4 CANa addr. 258 CANaux2_OUTaddress 2
5 CANa addr. 385 CANaux3_IN address 2
6 CANa addr. 386 CANaux3_OUT address 2
Save changes with C0003 = 1.
The settings are only accepted after carrying out one of the following actions:
ƒ Renewed switch−on of the 24 V low−voltage supply
ƒ Reset node via the bus system (by the network management (NMT))
ƒ Variable CAN_bResetNode_b or CANaux_bResetNode_b = TRUE
ƒ Reset node with C0358/2458 = 1
)
Note!
If reset node is executed via GDC, communication will be interrupted. You
therefore have to log in again manually or find the devices connected to the
bus once again (fieldbus scan).
