Appendix – Lenze ECSCPxxx User Manual
Page 385

Appendix
Code table
l
385
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0906
Analog input signals to MCTRL
Read only
1 MCTRL analog
−199.99
{0.01 %}
199.99 Speed controller input
2 MCTRL analog
Torque setpoint
3 MCTRL analog
Lower torque limit
4 MCTRL analog
Upper torque limit
5 MCTRL analog
Limit of the position controller
6 MCTRL analog
Speed for activating the torque
limitation
7 MCTRL analog
Field weakening
8 MCTRL analog
Integrator of the speed controller
9 MCTRL analog
P adaptation of the position
controller
C0907
Digital input signals to MCTRL
Only display
1 MCTRL digital
0
1 Activating position controller
2 MCTRL digital
Speed control or torque control
3 MCTRL digital
Set quick stop (QSP)
4 MCTRL digital
Loading integral−action
component of the speed
controller
C0908 MCTRL PosSet
Set phase signal
1 revolution = 65536 increments
Only display
−2147483648
{1 inc}
2147483647
C0909 speed limit
1
Limitation of direction of
rotation for speed setpoint
1
−175 ... +175 %
2
0 ... +175 %
3
−175 ... 0 %
C0910 MCTRL TP2
delay
0
MCTRL dead time compensation
TP2 (X6/DI2)
−32767
{1 inc}
32767 1 inc
º approx. 60 ms
C0911 MCTRL TP2
sel.
0
MCTRL touch probe signal source
0
Zero pulse of position encoder (C0490) X7/X8
1
Touch probe input TP2
X6/DI2
C0912 MCTRL TP2
Edge
0
MCTRL touch probe TP2 edge
(for touch probe via digital input
X6/DI2 (C0911 = 1))
0
Rising edge TP2
1
Falling edge TP2
2
Rising and falling edge TP2
3
Switched off
C1120 Sync mode
0
Sync signal source
^ 278
0
Off
Off
1
CAN sync
Sync connection via interface X4
(CAN)
^ 282
2
Terminal sync
Sync connection via terminal
X6/DI1
^ 283
