Appendix, Code table – Lenze ECSCPxxx User Manual
Page 378

Appendix
Code table
l
378
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
13 User menu
0.0
Not assigned
14 User menu
105.0
C0105
QSP Tif
Entry of deceleration time for
quick stop (QSP)
15 User menu
0.0
Not assigned
16 User menu
70.0
C0070
Vp speed CTRL
Input of gain for speed controller
17 User menu
71.0
C0071
Tn speed CTRL
Input of integral−action time for
speed controller
18 User menu
0.0
Not assigned
19 User menu
2100.0
C2100
Time slice
Input of time slice for cyclic task
20 User menu
2102.0
C2102
Task switch
Selection of switch function for
cyclic task
21 User menu
2104.0
C2104
PLC autorun
Automatic start of PLC program
after power−up
22 User menu
2106.0
C2106
Download protect
Write protection of PLC program
23 User menu
2108.0
C2108
PLC run/stop
PLC program control
24 User menu
2111.0
C2111
GDC ID
Creation date of PLC application
program
25 User menu
2113.0
C2113
PLC prog name
Name of PLC application
program
26 User menu
2115.0
C2115
T−Fct credit
Number of technology units
27 User menu
0.0
Not assigned
28 User menu
0.0
Not assigned
29 User menu
0.0
Not assigned
30 User menu
0.0
Not assigned
31 User menu
94.0
C0094
Password
32 User menu
3.0
C0003
Par save
Save parameter set
0.00
{0.01}
7999.00
l
Enter the numbers of the
required codes into the
subcodes.
l
Entry in the format xxxx.yy
– xxxx = code number
– yy = subcode of the code
l
It is not checked whether the
code entered exists.
[C0540] X8 Signal out
2
Function of the digital frequency
output signals at X8 (DFOUT)
^ 87
^ 136
^ 145
0
Reserved
1
Profile generator output
àDFOUT
2
Encoder simulation + zero pulse
à
DFOUT
C0545 PH offset
0
Phase offset
0
{1 inc}
65535 1 revolution = 65535 increments
C0547 DIS: AN−IN
Analog signal on the input of the
DFOUT block
Read only
−199.99
{0.00 %}
199.99
C0549 DIS: DF−IN
Speed on the input of the DFOUT
block
Only display
−32767
{1 rpm}
32767
