Appendix – Lenze ECSCPxxx User Manual
Page 403

Appendix
Code table
l
403
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C3095
Mode selection for positioning
profiles 1 ... 15
^ 191
1 Prof.Mode
1
modulo pos.
Positioning profile 1
... ...
...
...
...
15 Prof.Mode
1
modulo pos.
Positioning profile 15
0
absolute pos.
Absolute positioning
1
modulo pos.
Relative positioning in
continuous measuring system
2
speed mode
Constant traversing
3
relative pos.
Relative positioning with
absolute reference
10
absTP−rel_E3+
Absolute touch probe
positioning (positive edge at
X6/DI3)
11
modTP−rel_E3+
Relative touch probe positioning
(positive edge at X6/DI3)
13
relTP−rel_E3+
Relative touch probe positioning
with absolute reference (positive
edge at X6/DI3)
20
absTP−rel_E3−
Absolute touch probe
positioning (negative edge at
X6/DI3)
21
modTP−rel_E3−
Relative touch probe positioning
(negative edge at X6/DI3)
23
relTP−rel_E3−
Relative touch probe positioning
with absolute reference
(negative edge at X6/DI3)
30
EShaftX8_IS
Electrical shaft with setpoint via
X8 and instant start
31
EShaftX4_IS
Electrical shaft with setpoint via
X4 and instant start
100
homing
Homing
101
set home pos.
Set home position
102
reset home pos.
Reset home position
110
abs. direct
Absolute positioning (direct)
111
mod direct
Relative positioning in
continuous measuring system
(direct)
112
speed direct
Continuous constant travel
(direct)
113
rel. direct
Relative positioning with
absolute reference (direct)
251
mod cycle +/−
Positioning sequence for
controller optimisation
l
The distance travelled in
positive/negative direction is
selected under C3100.
