Commissioning
Holding brake configuration
l
131
EDBCSXP064 EN 8.0
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
[C0420] Encoder const.
512
Number of increments of the
encoder
^ 136
^ 145
1
{1 inc/rev}
8192 Sets C0419 = 0 ("common") if the
value is altered.
C4021 Brk: T_activ
500
Closing time of the motor
holding brake (engagement
time)
^ 130
0
{1 ms}
5000
C4022 Brk: T_releas
500
Release time of the motor
holding brake (disengagement
time)
^ 130
0
{1 ms}
5000
C4023 Brk: N_Thresh
0.1 %
Speed threshold for brake
activation
^ 130
0.00
{0.01 %}
10.00
C0118
Polarity of the digital outputs
(DIGOUT)
^ 172
1 DIGOUT pol
0
HIGH level active
X6/DO1
2 DIGOUT pol
0
HIGH level active
X25/BD1, X25/BD2
(brake connection)
0
HIGH level active
1
LOW level active
C0602 MONIT REL1
3
Fault response − open circuit
monitoring of relay output X25
0
TRIP
2
Message
3
Off
4
FAIL−QSP
