Appendix – Lenze ECSCPxxx User Manual
Page 387

Appendix
Code table
l
387
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C1202 Gear num
1
Gearbox factor numerator
The gearbox ratio specifies the
number of revolutions of the
motor axis at which the load
revolves exactly once.
l
i = Z2 / Z1 (ratio of the
number of teeth or
circumferences)
l
i = n1 / n2 (ratio of the
speeds)
^ 103
1
{1}
65535
C1203 Gear denom
1
Gearbox factor denominator
^ 103
1
{1}
65535
C1204 Feed const
360.0
The feed constant specifies the
path (in units) which the load
(slide) covers in one revolution.
^ 103
0.0001
{0.0001
units/rev}
214000.0000
C1240 Vel_max
18000.0
Max. permissible speed of the
load (slide).
Note: Enter the motor speed
resulting from Vel_max plus 10%
reserve in C0011!
^ 103
0.0001
{0.0001
units/s}
214000.0000
C1250 Acc_max
36000.0
Max. acceleration
Note: This parameter among
other things depends on the
motor torque and the moment
of inertia of the entire mechanics
driven during the positioning
process!
^ 103
0.0001
{0.0001
units/s
2
}
214000.0000
C1256 S−RMP: Jerk
1.0
The max. jerk is defined
according to a selected time
(t
jerk_max
) after which the max.
acceleration (a
max
) is reached.
Note:
If disproportionately high S−ramp
times (jerk times) are set for
short accelerating times, the
profile may be generated
incorrectly!
0.000
{0.001 s}
10.000
C1810 SW ID LECOM
Software identification LECOM
Only display
C1811 SW date
LECOM
Software creation date LECOM
Only display
C2100 Time slice
13
Time slice for cyclic task
6
{1 ms}
26
