Commissioning
Defining the window for standstill message
l
231
EDBCSXP064 EN 8.0
6.21
Defining the window for standstill message
The standstill message is activated if the actual speed falls below a certain speed limit
value (independent of the direction of rotation). The limit value (C3017) and hysteresis
(C3018) can be set in the GDC parameter menu under Positioning
W Machine parameters.
Function sequence
ƒ
If the current speed falls below the speed threshold (C3017), status bit Stat2.Nmin is
set to 1.
ƒ
Only when the current speed exceeds the value of C3017 + C3018 again, status bit
Stat2.Nmin is reset to "0".
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C3017 Lim.n=0−Flag
0.10
Limit value for speed, (n
min
signal)
^ 231
0.01
{0.01 %}
100.00 If the value falls below the limit
value, the status bit Stat2.Nmin
is set to 1.
C3018 Hyst.n=0−Flag
0.10
Hysteresis for speed (n
min
signal)
^ 231
0.00
{0.01 %}
100.00
