Appendix
Code table
l
383
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0858
Analog process data output
words are indicated decimally on
the AIF interface (AIF1_OUT)
100.00% = 16384
Read only
1 AIF1 OUT
words
−199.99
{0.01 %}
199.99 Output word 1
2 AIF1 OUT
words
Output word 2
3 AIF1 OUT
words
Output word 3
C0859 AIF1 OUT phi
32−bit phase information at the
AIF interface (AIF1_OUT)
Only display
−2147483648
{1}
2147483647
C0863
Digital process data input words
for CAN bus interface X4
Hexadecimal value is bit−coded.
Read only
^ 418
0000
{hex}
FFFF
1 CAN IN bits
Bit 0
...
Bit15 CAN1_IN: Process data input
word 1
2 CAN IN bits
Bit 16
...
Bit 31 CAN1_IN: Process data input
word 2
3 CAN IN bits
Bit 0
...
Bit15 CAN2_IN: Process data input
word 1
4 CAN IN bits
Bit 16
...
Bit 31 CAN2_IN: Process data input
word 2
5 CAN IN bits
Bit 0
...
Bit15 CAN3_IN: Process data input
word 1
6 CAN IN bits
Bit 16
...
Bit 31 CAN3_IN: Process data input
word 2
C0866
Analog process data input words
(decimal) for CAN bus interface
X4
100.00% = 16384
Read only
^ 418
1 CAN IN words
−199.99
{0.01 %}
199.99 CAN1_IN word 1
2 CAN IN words
CAN1_IN word 2
3 CAN IN words
CAN1_IN word 3
4 CAN IN words
CAN2_IN word 1
5 CAN IN words
CAN2_IN word 2
6 CAN IN words
CAN2_IN word 3
7 CAN IN words
CAN2_IN word 4
8 CAN IN words
CAN3_IN word 1
9 CAN IN words
CAN3_IN word 2
10 CAN IN words
CAN3_IN word 3
11 CAN IN words
CAN3_IN word 4
C0867
32−bit phase information for
CAN bus interface X4
Read only
1 CAN IN phi
−2147483648
{1}
2147483647 CAN1_IN
2 CAN IN phi
CAN2_IN
3 CAN IN phi
CAN3_IN
