Appendix – Lenze ECSCPxxx User Manual
Page 371

Appendix
Code table
l
371
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0361
Detected load
CAN_IN/CAN_OUT (CAN bus
interface X4)
Read only
A faultless operation is only
guaranteed if the total bus load
of all connected nodes amounts
to a value
£ 80 %.
^ 288
1 Load IN/OUT
0
{1 %}
100 All sent telegrams
2 Load IN/OUT
All received telegrams
3 Load IN/OUT
Sent to CAN1_OUT
4 Load IN/OUT
Sent to CAN2_OUT
5 Load IN/OUT
Sent to CAN3_OUT
6 Load IN/OUT
Sent on parameter data
channel 1
7 Load IN/OUT
Sent on parameter data
channel 2
8 Load IN/OUT
Received from CAN1_IN
9 Load IN/OUT
Received from CAN2_IN
10 Load IN/OUT
Received from CAN3_IN
11 Load IN/OUT
Received from parameter data
channel 1
12 Load IN/OUT
Received from parameter data
channel 2
C0362 Sync cycle
Time interval between 2 sync
telegrams via the X4 CAN bus
interface or EMF2192IB EtherCAT
communication module at X1 AIF
interface
Read only
^ 278
1
{1 ms}
30
C0363 Sync correct.
1
Sync correction increment (for
CAN and EtherCAT)
l
Change correction value until
C4264 reaches the minimum.
^ 279
1
0.2
ms/ms
2
0.4
ms/ms
3
0.6
ms/ms
4
0.8
ms/ms
5
1.0
ms/ms
C0365 DIS:CAN
active
Input signal CAN active
Only display
0
CAN not active
1
CAN active
C0366 Sync Response
1
CAN sync response for interface
X4 (CAN)
The value "1" should always be
set!
^ 281
0
No response
1
Response
