Configuration
Configuring MotionBus/system bus (CAN)
Axis synchronisation (CAN synchronisation)
l
280
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C4264 CanSync_Dev
0
Deviation of the control program
synchronisation
This also applies to
synchronisation via the digital
input X6/DI1.
Read only
^ 279
−32767
{1}
32767
CAN sync identifiers
The transmit and receive identifiers of the sync telegram can be configured via the
following codes:
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0367 Sync Rx ID
128
CAN sync receipt ID for CAN bus
interface X4
^ 280
1
{1}
256
C0368 Sync Tx Id
128
CAN Sync transmission ID for
CAN bus interface X4
^ 414
^ 278
1
{1}
256
C2467 Sync Rx ID
128
CAN−AUX sync receipt ID for CAN
bus interface X14
^ 280
1
{1}
256
C2468 Sync Tx ID
128
CAN−AUX Sync−transmission ID
for CAN bus interface X14
^ 414
^ 281
1
{1}
256
