Appendix
Code table
l
399
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C3013 Homing Vel
720.0
Homing speed
1.0000
{0.0001
units/s}
214000.0000
C3014 Homing Acc
720.0
Homing acceleration
1.0000
{0.0001
units/s
2
}
214000.0000
C3015 HomJerkTime
0.0
Homing − jerk time
0.000
{0.001 ms}
10.000
C3017 Lim.n=0−Flag
0.10
Limit value for speed, (n
min
signal)
^ 231
0.01
{0.01 %}
100.00 If the value falls below the limit
value, the status bit Stat2.Nmin
is set to 1.
C3018 Hyst.n=0−Flag
0.10
Hysteresis for speed (n
min
signal)
^ 231
0.00
{0.01 %}
100.00
C3020 ManualVel
360.0
Traversing speed for manual jog
(inching mode)
^ 173
0.0001
{0.0001
units/s}
214000.0000
C3021 ManualAcc
720.0
Acceleration for manual jog
(inching mode)
^ 173
0.0001
{0.0001
units/s
2
}
214000.0000
C3022 ManualDec
720.0
Deceleration for manual jog
(inching mode)
^ 173
0.0001
{0.0001
units/s
2
}
214000.0000
C3030 FollErrWarn
360.0
Following error tolerance
(warning)
^ 233
0.0000
{0.0001
units}
214000.0000 If the tolerance is exceeded, the
"FollowErr" warning will be
triggered. The status bit
Stat2.FollowErrWarn is set to "1"
(TRUE).
Note: The acceptance of changed
settings requires a status change
via the "Stand−By" status!
C3031 FollowErrQSP
720.0
Following error tolerance
(Fail−QSP)
^ 233
0.0000
{0.0001
units}
214000.0000 If the tolerance is exceeded, the
Fail−QSP "FollowErr" fault is
triggered and the drive is
stopped through the QSP ramp.
Note: The acceptance of changed
settings requires a status change
via the "Stand−By" status!
C3034 Target
Window
360.0
Total width of the target position
window
Layout: Half of the window
width before and after the target
position
^ 229
−0.0000
{0.0001
units}
65536.0000
