Appendix
Code table
l
357
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0062 Interior temp
Interior device temperature
Read only
^ 304
−200
{1
°C}
200
C0063 Mot temp
Motor temperature
Read only
^ 301
0
{1
°C}
200
C0064 Utilization
Device utilisation (I x t) over the
last 180 s
Only display
0
{1 %}
150
l
C0064 > 100 % activates
OC5−TRIP.
l
TRIP−RESET only is possible if
C0064 < 95 %.
C0065 U24 ext
External low−voltage supply
(U
24
)
Read only
0,0
{0.1V}
100,0
C0066 Motor load
Thermal motor load I
2x
t
Only display
^ 309
0
{1 %}
250
C0067 Act trip
Current fault (TRIP)
(in case of FAIL−QSP, warning and
message, "0" is displayed.)
Only display
^ 343
C0070 Vp speedCTRL
3.0
Proportional gain of speed
controller (V
pn
)
^ 252
0.00
{ 0.01}
127.99
C0071 Tn speedCTRL
24.0
Reset time − speed controller
(T
nn
)
^ 252
1.0
{0.5 ms}
6000.0
C0072 Td speedCTRL
0.0
Derivative gain of speed
controller (T
dn
)
^ 252
0.0
{0.1 ms}
32.0
C0074 Dynamics
0
Pilot control of the current
controller for higher dynamics
^ 247
0
Normal
1
Enhanced
C0075 Vp currCTRL
20.0
Proportional gain of current
controller (V
pi
)
The upper limit is
device−dependent.
^ 247
0.00
{0.01
W}
381.80 ECSxS/P/M/A004
190.90 ECSxS/P/M/A008
95.46 ECSxS/P/M/A016
47.72 ECSxS/P/M/A032
31.82 ECSxS/P/M/A048
23.86 ECSxS/P/M/A064
C0076 Tn currCTRL
5.0
Reset time of current controller
(T
ni
)
^ 247
0.01
{0.01 ms}
200.00
C0077 Vp fieldCTRL
5.0
Field controller gain (V
pF
)
^ 254
0.00
{0.01}
63.99
