Appendix – Lenze ECSCPxxx User Manual
Page 402

Appendix
Code table
l
402
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C3066 ProfilerState
State of the profile generator
Only display
15690
InvProfDist
Selected distance is too long or
not plausible!
15700
InvProfPar
Invalid profile parameter, travel
is not possible!
15788
ProfAuxVelEq0
Invalid value for speed of the
touch probe positioning;
e. g. value = 0
15789
ProfAuxDecEq0
Invalid value for deceleration of
the touch probe positioning;
e. g. value = 0
15790
ProfAuxAccEq0
Invalid value for acceleration of
the touch probe positioning;
e. g. value = 0
15798
ProfVelEq0
Invalid value for speed;
e. g. value = 0
15799
ProfDecEq0
Invalid value for deceleration;
e. g. value = 0
15800
ProfAccEq0
Invalid value for acceleration;
e. g. value = 0
16000
NoAction
No action
16001
PosDone
Positioning has been completed.
16010
Acceleration
Acceleration phase
16011
ConstSpeed
Constant travel phase (final
speed has been reached)
16012
Deceleration
Deceleration phase
16013
Reversing
Direction of rotation is reversed.
16100
ResetActive
Profile generator is reset to the
initial state.
16300
OverflowIntPos
Overflow of the internal position
integral
16101
LoadStartVal
Profile generator is loaded with
starting values.
16102
AbortActive
Positioning stopped
16103
ExtSetVal
External setpoint source is active.
16200
NoTPDetected
No touch probe signal
