Appendix
Code table
l
368
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0202
Service code
Only display
1
Product code 1
...
...
4
Product code 4
C0203 Komm.−No.
x / xxxx / xxxxx
Commission number
Only display
C0204 Serial−No.
Serial number
Read only
C0205 PLC Target ID
Identification key
Only display
C0206 Product. date
Production date
Only display
C0207 DL info 1
Download info 1
Only display
C0208 DL info 2
Download info 2
Only display
C0209 DL info 3
Download info 3
Only display
C0250 FCODE 1 Bit
0
Freely selectable digital signal
(1 bit)
0
1
C0254 Vp angle CTRL
0.4000
Phase controller gain (V
p
)
0.0000
{ 0.0001}
3.9999
C0300 Service Codes
Only the Lenze service is allowed
to make changes!
...
C0302
C0349
Status of the DIP switch for CAN
bus interface X4
Read only
1 CAN DIP−SW
0
{1}
63 Node address set on the DIP
switch
2 CAN DIP−SW
0
4 For setting the DIP switches > 4,
the display is set to 0.
C0350 CAN address
32
Node address for CAN bus
interface X4
l
This code is not active if one
of the switches 2 ... 7 of the
DIP switch is set to "ON".
(
^ 266)
l
After the setting process, a
reset node is required.
l
A definite node address must
be assigned to each CAN
node.
^ 266
^ 429
1
{1}
63
C0351 CAN baud rate
0
Baud rate for CAN bus interface
X4
l
The baud rate must be set
identically for all CAN nodes.
l
This code is not active if one
of the switches 2 ... 7 of the
DIP switch is set to "ON".
l
After the setting process, a
reset node is required.
^ 266
0
500 kbps
1
250 kbits/sec
2
125 kbit/s
3
50 kbps
4
1000 kbit/s
