Appendix – Lenze ECSCPxxx User Manual
Page 409

Appendix
Code table
l
409
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C4263 CanSetValCyc
Cycle time of the setpoint
selection at control program
synchronisation
Only display
2
{2 ms}
12
C4264 CanSync_Dev
0
Deviation of the control program
synchronisation
This also applies to
synchronisation via the digital
input X6/DI1.
Read only
^ 279
−32767
{1}
32767
C4265 MaxTargetInp
Max. target position input (in
units)
Read only
^ 103
−214000.0000
{0.0001
units}
214000.0000
C4266 PosRes
0
Lenze−internal parameter set
identifier
Read only
^ 103
0
{1
inc/unit}
2140000000 Position resolution in increments
per unit
1 revolution of position
encoder
¢ 65536 increments
C4270 CAN Ctrl1
CAN application control word 1
Read only
Text[1]=DIS: Ctrl1 appl. control word from CAN1−Out
Text[2]=DIS: Ctrl1 appl. control word from CANaux1−In
Text[3]=DIS: Ctrl1 appl. control word from AIF
Text[4]=DIS: Ctrl1 appl. control word from C4040
Text[5]=DIS: Ctrl1 appl. control word from CANaux2−In
Text[6]=DIS: Ctrl1 appl. control word from CAN3−In
C4271 CAN Stat1
CAN application status word 1
Read only
Text[1]=DIS: Stat1 appl. status word 1 to CAN1−Out
Text[2]=DIS: Stat1 appl. status word 1 to CANaux1−Out
Text[3]=DIS: Stat1 app. status word 1 to AIF1−Out
Text[4]=DIS: Stat1 appl. status word 1 to C4040
Text[5]=DIS: Stat1 appl. status word 1 to CANaux2−Out
Text[6]=DIS: Stat1 appl. status word 1 to CAN3−Out
C4272 CAN Stat2
CAN application status word 2
Read only
Text[1]=DIS: Stat2 appl. status word 2 to CAN1−Out
Text[2]=DIS: Stat2 appl. status word 2 to CANaux1−Out
Text[3]=DIS: Stat2 appl. status word 2 to AIF1
Text[4]=DIS: Stat2 appl. status word 2 to C4040
Text[5]=DIS: Stat2 appl. status word 2 to CANaux2−Out
Text[6]=DIS: Stat2 appl. status word 2 to CAN3−Out
C7900 L_GDC_Vers
Lenze−internal version
identification
(e.g. V1.2 = 1020000)
Read only
